eBike Velotric Summit 1 - Sunrise Orange - In a Box
Velotric Summit 1 - Sunrise Orange - In a Box Electric Bike
Velotric authorized dealer in San Diego & EscondidoVelotric warranty & support for Ready to Ride eBikes
Escondido eBike Super Shop serves the Escondido, San Diego, and greater Southern California community with local pickup support as well as shipping service.
The Velotric Summit 1 - Sunrise Orange - In a Box is a compact electric bike built for riders who want an easy, stylish way to handle short trips, neighborhood cruising, and everyday errands. Powered by a responsive motor with responsive power delivery and pedal-assist support, it delivers approachable performance up to city-friendly speeds, while a practical battery system and useful everyday range help support regular day-to-day riding. Its compact proportions help keep the ride manageable and approachable. compact wheels and city-friendly proportions help the bike stay practical for everyday use.
This product is not currently in store, but it can be ordered right now.
Key Features
- 48V 750W Motor (90Nm): High-torque output for quick acceleration and confident hill climbing.
- SensorSwap™ (Torque/Cadence): Supports torque and cadence sensing for tailored responsiveness and efficiency.
- Up to 70 Miles Pedal Assist Range: Matched with a 48V, 705.6Wh battery for extended ride capability.
- UL 2271 Certified, IPX7 Battery: High-energy density battery with UL 2271 certification and IPX7 waterproof rating.
- 120mm Hydraulic Suspension w/ Lockout: 120mm travel helps absorb impacts; lockout supports efficient riding.
- SHIMANO Hydraulic Disc Brakes (180mm): 180mm front and rear rotors for strong, controlled braking performance.
Specifications
| Feature | Details |
|---|---|
| Bike Size | Regular / Large |
| User Height Range | Regular: 5'1" ~ 5'10" / Large: 5'8" ~ 6'6" |
| Frame | Triple-Butted Aluminum Alloy |
| Fork | Hydraulic suspension 120mm travel with Lock-out, 15x110mm thru-axle |
| Motor | 48V, 750W, 90Nm |
| Battery | 48V, 705.6Wh, IPX7, Certificated by UL 2271 |
| Cell | Samsung/LG 21700 cell, Certificated by UL 2580 |
| Charger | 48V, 3A Fast Charger |
| Sensor | Torque/Cadence |
| Display | 2.8" Full color, high brightness, Bluetooth, adjustable angle |
| USB Port | USB Type-A phone charge |
| Security | Apple Find My™ |
| Throttle | Trigger-control, removable |
| Pedal Assist | 3 Modes × 5 Levels |
| Walk Mode | 2.9 MPH |
| Front Light | Light sensing 130Lux high-output integrated LED, adjustable angle |
| Rear Light | Brake highlight, rear light steady/flash |
| Water Resistant | IPX6 |
| Default Speed | 20 MPH |
| Max Speed Adjustable Range | 12~28 MPH |
| Class | 1/2/3 |
| Throttle Range | 60 Miles |
| Pedal Assist Range | 70 Miles |
| Chainrings | BCD 104, narrow wide chainring |
| Crankset | Aluminum Alloy, 170mm |
| Cassette | 8-speed |
| Rear Derailleur | SHIMANO 8-speed |
| Shift Lever | SHIMANO 8-speed |
| Chain | KMC 8-speed |
| Brake | SHIMANO Hydraulic Disc Brake |
| Rotors | 180mm front and rear |
| Brake Levers | Aluminum Alloy, with power cutoff |
| Rims | Double-wall Aluminum Alloy |
| Front Hub | NOVATEC Aluminum Alloy, 15x110mm thru-axle |
| Tire | Kenda 27.5x2.6" MTB puncture resistant tires |
| Handlebar | Aluminum Alloy, Φ31.8mm, 760mm (R)/780mm (L) |
| Grips | Velotric sports grips, lockable |
| Stem | Aluminum Alloy, φ31.8mm, 35mm (R)/50mm (L) |
| Saddle | VELOTRIC ergonomic seat |
| Seatpost | Aluminum Alloy, φ30.9mm, 350mm |
| Clamp | Aluminum Alloy, quick release |
| Fenders | Optional |
| Rear Rack | Optional |
| Pedals | Aluminum Alloy |
| Kickstand | Aluminum Alloy, included, rear mount |
| Bike Weight | 62lbs |
| Max Bike Load Capacity | 440lbs |
| UL Certification | UL 2849 |
| ISO Standard | ISO 4210 |
Size & Geometry
| Measurement | Regular | Large |
|---|---|---|
| Rider Height | 5'1'' ~ 5'10'' | 5'8'' ~ 6'6'' |
| Seat Tube Length | 410mm | 475mm |
| Head Tube Length | 130mm | 135mm |
| Stack | 644mm | 649mm |
| Reach | 388mm | 402mm |
| Stand-Over Height | 710mm | 749mm |
| Top-Tube Length (horizontal) | 610mm | 690mm |
| Min Saddle Height | 775mm | 830mm |
| Max Saddle Height | 945mm | 1001mm |
Manufacturers Warranty: https://www.velotricbike.com/pages/warranty
User Manual: https://cdn.shopify.com/s/files/1/0877/9435/2404/files/eBike_Velotric_Summit_1_User_Manual.pdf?v=1770584316
Assembly & Build Options
The “In a Box” option is delivered in the manufacturer’s original packaging and arrives unassembled. Professional assembly is required prior to riding, including proper installation, torque verification, and a complete safety inspection of all components.
This option does not include assembly services, safety inspection, tuning, or ongoing service support from our retail location. All warranty claims, technical support, and product-related concerns must be handled directly with Velotric through the manufacturer’s official support channels.
Why Choose This Model?
What helps the Velotric Summit 1 - Sunrise Orange - In a Box stand apart is the way it combines compact proportions with practical electric-bike capability. With its responsive motor, speeds up to controlled, compact setup, its battery system, and useful daily range, it presents a useful balance of approachability and everyday function.
Customers shopping with Escondido eBike Super Shop may appreciate how naturally it fits into short trips, errands, and everyday transportation.
Explore More
Explore more commuter-friendly, compact, and city-ready eBikes at Escondido eBike Super Shop, where everyday practicality, approachable design, and useful electric mobility remain central to the lineup.
Escondido eBike Super Shop supports local riders in Escondido and San Diego while also giving customers nationwide access through shipping available across the USA.
